CYCTRAC EM8 Carbon Electric Mountain Bike

CYCTRAC

Overview

500W
Motor

672Wh
Samsung battery

25 km/h default
Assistance setting

115-135 km
Maximum pedal-assist range

150 KG
Maximum load

CYCTRAC EM8

EM8 Carbon Electric Mountain Bike

One model. Three considered configurations. Choose Standard, Pro or Max, then select your colour and frame size.

Mid-drive assistance

Bafang Mid, M560, 48V500W. Maximum torque: 140 Nm. Torque+Cadence, Throttle available.

Energy for the ride

Samsung 21700 Li-ion,672Wh, 48V14A. Max 115-135KM (pedal assist). Listed full charge time: 5-6 Hours. Actual range and charging time depend on conditions.

A frame built around your ride

CYCTRAC, EM8, High modulus Carbon fiber, XC, Inner cables, Thru-axle12*148 Boost. Available wheel and frame sizes: 27.5×17", 27.5×19", 29×17", 29×19".

Suspension to match your configuration

Standard: RS, MgAl alloy,Air, Remote,Thru-axle 15*110. Pro: ROCKSHOX-JUDYS, Air,Remote,Thru-axle 15*110. Max: ROCKSHOX-JUDYS, Air,Remote,Thru-axle 15*110.

Braking with control

SHIMANO MT200 hydraulic disc brake,180/180mm.

Choose your shifting system

Standard: SHIMANO DEORE/M6100-12S. Pro: SHIMANO DEORE/M6100-12S. Max: Wheeltop EDS OX-12S wireless. Compare the components below before choosing your configuration.

Ride information at a glance

Bafang-C245, LCD digital, USB/Type-C, Bluetooth/BafangGo App.

Configuration comparison

eBike Specs	M6100-12S LOW	M6100-12S HIGH	WheelTop-12S Wireless HIGH
Net Weight	20.9KG	21.0KG	21.1KG
Fork	RS, MgAl alloy,Air, Remote,Thru-axle 15*110	ROCKSHOX-JUDYS, Air,Remote,Thru-axle 15*110	ROCKSHOX-JUDYS, Air,Remote,Thru-axle 15*110
Shifter	SHIMANO DEORE/M6100-12S	SHIMANO DEORE/M6100-12S	Wheeltop EDS OX-12S wireless
Rear Derailleur	SHIMANO DEORE/M6100-12S	SHIMANO DEORE/M6100-12S	Wheeltop EDS OX-12S wireless

Technical specifications

Specification	EM8
Frame Size	27.5×17" / 27.5×19" / 29×17" / 29×19"
Bike Color	Dark Gray / Black / Dark Green
Frame	CYCTRAC, EM8, High modulus Carbon fiber, XC, Inner cables, Thru-axle12*148 Boost
Handlebar set	RS, Alu alloy,Matte,Handlebar 31.8×720,Stem 60mm,Seat post 31.6×350mm,Clamps 34.9mm
Headset	Inner-Cables routing, Sealed bearings 52*52mm
Cranksets	Matching with Mid Motor, 38T
Cassettes	SUNSHINE-12S,11-50T
Chain	SUMC-12S
Brake	SHIMANO MT200 hydraulic disc brake,180/180mm
Hub	RS, Alu alloy,4-sealed Bearings,HG,Disc,32Holes,Thru-axle F15×110_R12×148mm Boost
Rim	RS, Alu alloy with Double-wall&Rivets, W30×H21mm
Spoke	SHUNJIU, Circular 14G
Tire	MAXXIS, 29/27.5×2.4"
Grips	Circular 22.2×120mm, PU leather&locking Ring
Saddle	RS, Comfortable and Thickened for MTB
Pedals	RS, Alu alloy&Skid resistant for MTB
Motor System	Bafang Mid, M560, 48V500W
Max Torque	140 Nm
Speed Limit	25KMh Default (max 45KMh)
Pedal Sensor	Torque+Cadence, Throttle available
Battery	Samsung 21700 Li-ion,672Wh, 48V14A
Maximum pedal-assist range	Max 115-135KM (pedal assist)
Full charge time	5-6 Hours
Charger	3A, DC2.1
Display	Bafang-C245, LCD digital, USB/Type-C, Bluetooth/BafangGo App
Water resistance	IP X6
Max Load	150 KG

Range is the listed maximum in pedal-assist mode; actual range varies with rider, terrain, weather and assist level. Standard speed setting: 25 km/h. Component photographs illustrate the model; use the selected configuration specifications for the supplied equipment.

Free shipping to 35+ countries/regions · Duties included. Motor and frame: 2 years. Other non-wear components, including the battery: 1 year. Wear parts: 7 calendar days from delivery against manufacturing defects. Normal wear and tear is excluded. Applicable statutory consumer rights remain unaffected. See the shipping and warranty policies for full terms.

Your configuration

Specifications

Specifications come from the model listing and vary by configuration. Confirm your fit, delivery terms and the model's suitability for local road rules before ordering.

Find my size

Use Find my size to enter your height, inseam and riding preference. Review the suggested frame together with the model geometry and standover clearance.

Frequently asked questions

How do I choose a configuration?

Choose Standard, Pro or Max, then select your color and frame size. Each option displays the component code and actual price. The specification table highlights your selected configuration.

Which frame size is right for me?

Use Find my size to enter your height, inseam and riding preference. Review the suggested frame together with the model geometry and standover clearance.

Where can I find delivery information?

Estimated transit after dispatch: Asia 25 calendar days; North America 45–50; Australia and Central Asia 35–40; Europe, South Africa and the Middle East 55–60. Processing or production time is additional. Other existing destinations retain their published timing; see the Shipping & Delivery Policy for your address.

Shipping & Delivery →

What warranty and support are available?

Motor and frame: 2 years. Other non-wear components, including the battery: 1 year. Wear parts: 7 calendar days from delivery against manufacturing defects. Normal wear and tear is excluded. Applicable statutory consumer rights remain unaffected.

Warranty Policy →
