Motor: 500W
Samsung battery: 720Wh
Assistance setting: 25 km/h default
Maximum pedal-assist range: 120-140 km
Maximum load: 160 KG

CYCTRAC

EC1 (SP)

Explore the EC1 collection for everyday journeys and relaxed weekend rides.

$1,727.80 USD

Configuration

ConfigurationRS-10S

StandardRS-10S ProM4100-10S MaxM6100-12S

ColorMatte Black

Frame size27.5-inch wheels / 16-inch frame

27.5-inch wheels / 16-inch frame

Optional upgrades

Choose your extras. Upgrade prices are per bike.

Speed remapSoftware remap to unlock a 45 km/h speed limit. Free ThrottleAdd a throttle to your bike. Free 750W motor upgradeReplace the standard motor with a 750W motor. +$60

Free shipping to 35+ countries/regions · Duties included

DeliveryShipping information →

Your configuration

RS-10S / Matte Black / 27.5-inch wheels / 16-inch frame

Delivery information Motor & Frame: 2-Year Warranty Real Human Support

Need help choosing your configuration? →

Specifications come from the model listing and vary by configuration. Confirm your fit, delivery terms and the model's suitability for local road rules before ordering.

CYCTRAC

Overview

500W
Motor

720Wh
Samsung battery

25 km/h default
Assistance setting

120-140 km
Maximum pedal-assist range

160 KG
Maximum load

CYCTRAC EC1

EC1 (SP) Electric Bike

One model. Three considered configurations. Choose Standard, Pro or Max, then select your colour and frame size.

Mid-drive assistance

Bafang Mid, M560, 48V500W. Maximum torque: 140 Nm. Torque+Cadence, Throttle available.

Energy for the ride

Samsung 21700 Li-ion,720Wh, 48V15A. Max 120-140KM (pedal assist). Listed full charge time: 5-6 Hours. Actual range and charging time depend on conditions.

A frame built around your ride

CYCTRAC, EC1, Alu alloy AL6061-T6,Flat weld&Smooth,Inner cables. Available wheel and frame sizes: 27.5-inch wheels / 16-inch frame.

Suspension to match your configuration

Standard: RS, Alu alloy,Coil suspension,Manual-lockout. Pro: RS, Alu alloy,Coil suspension,Manual-lockout. Max: RS, Alu alloy,Coil suspension,Manual-lockout.

Braking with control

SHIMANO MT200 hydraulic disc brake,180/180mm.

Choose your shifting system

Standard: RS(LTWOO) V5010-10S. Pro: SHIMANO DEORE/M4120-10S. Max: SHIMANO DEORE/M6100-12S. Compare the components below before choosing your configuration.

Ride information at a glance

CYC-C101, LCD digital, USB/Type-C.

Configuration comparison

eBike Specs	RS-10S	M4100-10S	M6100-12S
Net Weight	22.5KG	22.5KG	22.7KG
Shifter	RS(LTWOO) V5010-10S	SHIMANO DEORE/M4100-10S	SHIMANO DEORE/M6100-12S
Rear Derailleur	RS(LTWOO) V5010-10S	SHIMANO DEORE/M4120-10S	SHIMANO DEORE/M6100-12S
Cassettes	SUNSHINE-10S,11-36T	SUNSHINE-10S,11-36T	SUNSHINE-12S,11-50T
Chain	SUMC-10S	SUMC-10S	SUMC-12S

Technical specifications

Specification	EC1
Frame Size	27.5-inch wheels / 16-inch frame
Bike Color	Matte Black / Cement Gray
Frame	CYCTRAC, EC1, Alu alloy AL6061-T6,Flat weld&Smooth,Inner cables
Handlebar set	RS, Alu alloy,Matte,Handlebar 31.8×720,Stem 60,Seat post 31.6×350,Clamps 34.9mm QR
Fork	RS, Alu alloy,Coil suspension,Manual-lockout
Headset	Inner-Cables routing, Sealed bearings 52*52mm
Cranksets	Matching with Mid Motor, 38T
Brake	SHIMANO MT200 hydraulic disc brake,180/180mm
Hub	RS Alu alloy, 2-sealed Bearings,HG,Disc,32Holes
Rim	RS, Alu alloy with Double-wall&Rivets, W30×H21mm
Spoke	SHUNJIU, Circular 14G
Tire	CST, 27.5×2.4"
Grips	Circular 22.2×120mm, PU leather&locking Ring
Saddle	RS, Comfortable and Thickened for MTB
Pedals	RS, Alu alloy&Skid resistant for MTB
Motor System	Bafang Mid, M560, 48V500W
Max Torque	140 Nm
Speed Limit	25KMh Default (max 45KMh)
Pedal Sensor	Torque+Cadence, Throttle available
Battery	Samsung 21700 Li-ion,720Wh, 48V15A
Maximum pedal-assist range	Max 120-140KM (pedal assist)
Full charge time	5-6 Hours
Charger	3A, DC2.1
Display	CYC-C101, LCD digital, USB/Type-C
Water resistance	IP X6
Max Load	160 KG

Range is the listed maximum in pedal-assist mode; actual range varies with rider, terrain, weather and assist level. Standard speed setting: 25 km/h. Component photographs illustrate the model; use the selected configuration specifications for the supplied equipment.

Free shipping to 35+ countries/regions · Duties included. Motor and frame: 2 years. Other non-wear components, including the battery: 1 year. Wear parts: 7 calendar days from delivery against manufacturing defects. Normal wear and tear is excluded. Applicable statutory consumer rights remain unaffected. See the shipping and warranty policies for full terms.

Your configuration

Specifications

Specifications come from the model listing and vary by configuration. Confirm your fit, delivery terms and the model's suitability for local road rules before ordering.

Find my size

Use Find my size to enter your height, inseam and riding preference. Review the suggested frame together with the model geometry and standover clearance.

Frequently asked questions

How do I choose a configuration?

Choose Standard, Pro or Max, then select your color and frame size. Each option displays the component code and actual price. The specification table highlights your selected configuration.

Which frame size is right for me?

Use Find my size to enter your height, inseam and riding preference. Review the suggested frame together with the model geometry and standover clearance.

Where can I find delivery information?

Estimated transit after dispatch: Asia 25 calendar days; North America 45–50; Australia and Central Asia 35–40; Europe, South Africa and the Middle East 55–60. Processing or production time is additional. Other existing destinations retain their published timing; see the Shipping & Delivery Policy for your address.

Shipping & Delivery →

What warranty and support are available?

Motor and frame: 2 years. Other non-wear components, including the battery: 1 year. Wear parts: 7 calendar days from delivery against manufacturing defects. Normal wear and tear is excluded. Applicable statutory consumer rights remain unaffected.
